AQUAFIX®SEPARATORS FROM POLYETHYLENE - SERIES P

AQUAFIX®SEPARATORS FROM POLYETHYLENE - SERIES P

AQUAFIX

  • highest cleaning performances
  • modern materials for all demands
  • up to NS 250 l/sec.



AQUAFIX 10 PE - KPE Coalescence separator
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
KPE 03
 1635 1200 1040 100 850 830 107,0 383503
KPE 06
 1810 1200 1040 150 800 780 149,0 383506
KPE 08
 2310 1200 1040 150 800 780 167,0 383508
KPE 10
 2910 1200 1040 150 800 780 182,0 383510
KPE 15
 3515 1200 1040 200 740 720 241,0 383515



AQUAFIX 10 PE - SKPE Coalescence separator with sludge trap
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
SKPE 01,5/0150
 1635 1200 1040 100 850 830 116,0 384001
SKPE 03/0300
 1895 1200 1040 100 850 830 128,0 384003
SKPE 06/0600
 2310 1200 1040 150 800 780 176,0 384006
SKPE 08/0800
 2910 1200 1040 150 800 780 188,0 384008
SKPE 10/1000
 4255 1200 1040 150 810 780 280,0 384010
SKPE 15/1500
 4915 1200 1040 200 780 760 301,0 384015



AQUAFIX 10 PE - SKBPPE Coalescence separator with sludge trap and bypass
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
SKBPPE 06/0600
 2910 1200 1040 300 640 630 203,0 383606
SKBPPE 08/0800
 4255 1200 1040 300 650 630 285,0 383608
SKBPPE 10/1000
 4505 1200 1040 300 650 630 297,0 383610



AQUAFIX 10 PE - SKmPPE Coalescence separator with sludge trap and pump chamber
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
SKmPPE 01,5/0150
 2980 1200 1040 100 850 830 205,0 384401
SKmPPE 03/0300
 3240 1200 1040 100 850 830 217,0 384403
SKmPPE 06/0600
 3655 1200 1040 150 800 780 265,0 384406
SKmPPE 08/0800
 4255 1200 1040 150 800 780 287,0 384408
SKmPPE 10/1000
 5600 1200 1040 150 810 780 369,0 384410
SKmPPE 15/1500
 6260 1200 1040 200 780 750 390,0 384415



AQUAFIX 10 PE - SPE Sludge trap
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
SPE 0800/0160
 1675 1200 1040 150 810 800 92,0 384308
SPE 1000/0160
 1675 1200 1040 150 810 800 92,0 384310
SPE 1500/0200
 2335 1200 1040 200 780 760 122,0 384315
SPE 2000/0200
 2935 1200 1040 200 760 740 145,0 384320



AQUAFIX 10 PE - FPE Grease separator
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
FPE 02
 1675 1200 1040 150 790 770 95,0 385002
FPE 04
 1925 1200 1040 150 800 780 107,0 385004
FPE 07
 2324 1200 1040 150 800 780 124,0 385007
FPE 10
 2935 1200 1040 150 800 780 141,0 385010
FPE 15
 4280 1200 1040 200 760 740 238,0 385015



AQUAFIX 10 PE - SFPE Grease separator with sludge trap
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
SFPE 02/0200
 1675 1200 1040 150 800 780 103,0 385302
SFPE 04/0400
 2335 1200 1040 150 800 780 134,0 385304
SFPE 07/0700
 2935 1200 1040 150 800 780 156,0 385307
SFPE 10/1000
 4280 1200 1040 150 810 780 238,0 385310



AQUAFIX 10 PE - SAPE Starch separator
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
SaPE 01
 1675 1200 1040 150 790 770 93,0 386201
SaPE 02
 1935 1200 1040 150 800 780 102,0 386202
SaPE 03
 2335 1200 1040 150 800 780 124,0 386203
SaPE 04
 2935 1200 1040 150 800 780 145,0 386204



AQUAFIX 10 PE - NPE Battery acid neutraliser
  Length mm Width mm Height mm DN in-/outLet mm HE H inlet mm HA H outlet mm Weight kg Item No.
NPE 03
 1675 1200 1040 150 790 770 457,0 386903
NPE 04
 1935 1200 1040 150 800 780 539,0 386904
NPE 05
 2325 1200 1040 150 800 780 697,0 386905
NPE 06
 2925 1200 1040 150 800 780 790,0 386906
